Reliable Self-service Ticketing Solution

Cashless Ticket Vending Machines solve one of the biggest challenges in modern public transit: enabling passengers to purchase tickets or recharge travel cards quickly without depending on staffed counters. They reduce waiting time, improve passenger flow during peak hours, and support uninterrupted ticketing operations while providing multiple payment methods for a convenient commuter experience.

Aurotoshi is among the Cashless Ticket Vending Machine Manufacturers in India, offering compact self-service ticketing solutions designed for metro, rail, and urban transit applications. Built for continuous public operation, these machines integrate with AFC systems and support contactless payments, card recharge, QR ticketing, and other digital transit requirements. Each system is engineered for reliability, accessibility, and long-term performance in Indian operating conditions.

Features

15-inch Touchscreen Icon

15-inch Touchscreen

A capacitive touchscreen gives passengers a clear, direct interface for selecting and purchasing tickets.

QR Ticket Printing Icon

QR Ticket Printing

The integrated 58 mm thermal printer produces tickets at up to 120 mm/s, supporting fast self-service transactions.

Cashless Payment Interface Icon

Cashless Payment Interface

An optional card reader supports contactless technologies including MIFARE, DESFire and NFC, with EMV Level 1 and Level 2 support.

Optional 2D Scanner Icon

Optional 2D Scanner

A high-performance 2D barcode scanner can be added for applications that require QR or barcode scanning.

Compact Wall-Mounted Design Icon

Compact Wall-Mounted Design

At 480 × 120 × 730 mm, the CTVM provides self-service ticketing without the floor space required by a full-size cash TVM.

Feature 6 - Local Language Support Icon

Feature 6 - Local Language Support

The passenger interface is available in English and can be customised for local languages according to project requirements.

Cashless Ticket Vending Machine (TVM) Decorative Pattern

Aurotoshi is among the Cashless Ticket Vending Machine Manufacturers in India, providing compact self-service ticketing solutions for metro stations, railway networks, BRT systems, and urban transportation facilities. These machines enable passengers to purchase tickets and recharge eligible travel cards without depending on staffed ticket counters.

Designed for continuous public use, Aurotoshi Cashless Ticket Vending Machines combine a touchscreen interface, digital payment capabilities, thermal ticket printing, optional QR and barcode scanning, and integration with automated fare collection systems. The compact design makes them suitable for transit locations where reliable ticketing is required but available floor space is limited.

A Self Service Kiosk India solution can help transportation operators provide faster and more convenient passenger services while reducing queues at staffed counters. Cashless ticket vending kiosks allow passengers to independently select their journey, complete the required payment, and receive their ticket through an intuitive self-service interface.

Aurotoshi's self-service kiosks are designed around the practical requirements of public transportation environments. The 15-inch capacitive touchscreen provides a clear passenger interface, while optional payment and scanning modules can support contactless cards, NFC, EMV transactions, QR codes, and other project-specific requirements.

The wall-mounted configuration also helps transit operators make efficient use of station space while maintaining an accessible and easy-to-use ticketing point.

As an Interactive Kiosk Manufacturer, Aurotoshi develops configurable kiosk solutions that combine passenger-friendly interfaces with reliable computing, payment, scanning, and ticket-printing technologies.

The Auro-TA-CTVM features an Intel Core i5 processor, 8GB RAM, 256GB SSD storage, a 15-inch capacitive touchscreen, and a 58 mm thermal printer with print speeds of up to 120 mm/s. Optional 2D barcode scanning and card-reader capabilities allow the configuration to be adapted to different transit ticketing and payment requirements.

The kiosk can also be customised for local languages, connectivity requirements, and integration with the operator's existing transportation ticketing infrastructure.

Cashless ticketing provides passengers with a convenient alternative to traditional cash-based ticket counters. In busy metro and railway environments, self-service machines can help distribute passenger transactions across multiple points and reduce dependence on staffed ticket windows.

Aurotoshi Cashless Ticket Vending Machines can support contactless payment technologies including MIFARE, DESFire, NFC, and EMV Level 1 and Level 2, depending on the selected configuration. An optional 2D barcode scanner can also support QR and barcode-based applications.

This flexibility allows the machine to be configured according to the fare collection system, ticketing process, payment ecosystem, and passenger requirements of the transportation project.

Space availability is an important consideration when deploying ticketing equipment in existing transit facilities. Aurotoshi's Cashless Ticket Vending Machine has a compact wall-mounted design measuring 480 × 120 × 730 mm, allowing self-service ticketing to be installed without the floor space required by a conventional floor-standing TVM.

The compact configuration can be considered for station concourses, metro entry areas, railway facilities, BRT locations, and other passenger-processing environments where efficient use of available space is important.

A self-service ticketing system needs to be easy for passengers to use while supporting reliable operation in a public environment. Aurotoshi's Cashless Ticket Vending Machines combine a capacitive touchscreen interface with ticket printing, optional payment readers, barcode scanning, and local-language customisation.

The front panel is IP54 compliant, while the system can be configured with project-specific payment and ticketing components. These features help create a practical self-service experience for passengers while supporting the operational requirements of transit operators.

Aurotoshi combines manufacturing and engineering capabilities to provide configurable self-service ticketing solutions for modern transportation networks. Its Cashless Ticket Vending Machines are designed for continuous public use and can be adapted to the requirements of metro, railway, BRT, and urban transit projects.

Key advantages include:

  • 15-inch capacitive touchscreen
  • Contactless, NFC and EMV payment support
  • Optional 2D barcode and QR scanning
  • 58 mm thermal ticket printer
  • Print speed up to 120 mm/s
  • Intel Core i5 processor
  • Compact wall-mounted configuration
  • Local language customisation
  • IP54-compliant front panel
  • Ethernet connectivity
  • Project-specific system integration
  • CE-certified configuration

For transit operators, EPC contractors, system integrators, and transportation infrastructure projects, Aurotoshi can support the selection and configuration of cashless ticket vending solutions according to passenger flow, available space, payment requirements, and existing ticketing infrastructure.

Models & Specifications

Choose Your Specification

Choose from our range of high performance variants tailored to your specific facility requirements.

Auro-TA-CTVM
Application Mass transit application
Display 15 inch capacitive touch screen
CPU Intel Core i5 processor
RAM 8GB DDR3
Storage 256GB SSD
Operating System Microsoft Windows
Ethernet 2 x Gigabit Ethernet
Printer 58 mm thermal, 203 DPI, 120 mm/s print speed
Scanner (optional) High-performance 2D barcode scanner, 0 to 100,000 LUX
Card Reader (optional) ISO 14443 A/B, Mifare, DesFire, ISO 18092 (NFC), EMV L1 & L2, 4 SAM slots ID-000
Loud Speaker 2 x 3 W stereo speaker
Power Supply 180 to 250 VAC, 200 W
Mounting Wall mount
Dimensions (W x D x H) 480 x 120 x 730 mm
Language English, customizable to local languages
Front Panel Protection IP54 compliant
Certification CE
Auro-TA-CTVM
Application Mass transit application
Display 15 inch capacitive touch screen
CPU Intel Core i5 processor
RAM 8GB DDR3
Storage 256GB SSD
Operating System Microsoft Windows
Ethernet 2 x Gigabit Ethernet
Printer 58 mm thermal, 203 DPI, 120 mm/s print speed
Scanner (optional) High-performance 2D barcode scanner, 0 to 100,000 LUX
Card Reader (optional) ISO 14443 A/B, Mifare, DesFire, ISO 18092 (NFC), EMV L1 & L2, 4 SAM slots ID-000
Loud Speaker 2 x 3 W stereo speaker
Power Supply 180 to 250 VAC, 200 W
Mounting Wall mount
Dimensions (W x D x H) 480 x 120 x 730 mm
Language English, customizable to local languages
Front Panel Protection IP54 compliant
Certification CE

Where These Doors Are Installed

Industries & Applications

Engineered for diverse industrial and commercial environments, our solutions are trusted across a wide range of industries and applications.

No industries assigned yet. Please assign industries from the product edit page in the backend.

Projects & Case Studies

Installed & Running

See how our solutions are helping businesses improve operational efficiency, safety, and reliability across diverse industries.

No projects or case studies added yet. Please add them from the back panel.

Frequently Asked Questions

Buyer's Questions, Answered

Common queries from facility managers, procurement heads, and plant engineers.

A Cashless Ticket Vending Machine is a self-service kiosk that allows passengers to purchase tickets or recharge eligible travel cards without depending on a staffed counter. Aurotoshi's Auro-TA-CTVM supports cashless payment options and QR ticketing, helping reduce queues and improve passenger flow at metro, railway, and urban transit facilities.

The Cashless Ticket Vending Machine supports cashless payment and bank-card transactions. Depending on the configuration, the optional card reader supports ISO 14443 A/B, MIFARE, DESFire, NFC through ISO 18092, and EMV Level 1 and Level 2. The system can also be configured for QR and barcode-based ticketing applications.

Yes. The kiosk is designed with passenger usability and accessibility in mind. It features a 15-inch capacitive touchscreen and stereo audio output to provide clear visual and audio interaction. Final accessibility configurations can be adapted according to project requirements and applicable standards.

The Auro-TA-CTVM features a 15-inch capacitive touchscreen and an Intel Core i5 processor with 8GB DDR3 RAM and 256GB SSD storage. It operates on Microsoft Windows and includes dual Gigabit Ethernet connectivity for communication with ticketing and back-office systems.

The machine uses an integrated 58 mm thermal printer with 203 DPI resolution and a print speed of up to 120 mm/s. It can print QR-based tickets and other project-specific ticket formats according to the requirements of the transportation ticketing system.

Yes. The Cashless Ticket Vending Machine can connect to station ticketing, fare collection, and back-office systems through dual Gigabit Ethernet connectivity. The passenger interface is available in English and can be customised for local languages according to project requirements.

The Auro-TA-CTVM operates on 180 to 250 VAC with a power consumption of approximately 200 W. It is designed for wall mounting and has compact dimensions of 480 × 120 × 730 mm, making it suitable for transit locations where floor space is limited.

Yes. Aurotoshi supports OEM and ODM requirements for Cashless Ticket Vending Machines and self-service transportation solutions. The company can work with transit operators, system integrators, EPC contractors, and project partners to provide customised configurations, technical documentation, and integration support.

Cashless Ticket Vending Machines are commonly used in metro stations, railway stations, BRT systems, urban transit facilities, and other public transportation environments. They are particularly useful where operators want to provide self-service ticketing and digital payment options while making efficient use of available space.

Yes. A Cashless Ticket Vending Machine can be integrated with project-specific Automated Fare Collection (AFC) and transportation ticketing systems. Depending on the project architecture, the machine can support ticket issuance, card recharge, digital payments, QR or barcode processing, and communication with central ticketing or back-office platforms.

After Installation

Service & AMC for
Cashless Ticket Vending Machine (TVM)

We don't disappear after installation. Structured AMC, 24-hour breakdown response, in-house spare parts dispatched from Ghaziabad.

Preventive Maintenance
Quarterly AMC
  • Touch screen and printer servicing
  • Card reader and scanner check
  • Thermal-printer head and roller cleaning
  • Network and software update
  • Power-supply and speaker test
Breakdown Support
24-Hour Response
  • 24-hour response for AMC customers
  • In-house spare parts, no import lead times
  • Trained engineers across Delhi NCR, Mumbai, Pune
  • Priority response for live transit stations
Compliance & Records
Compliance Records
  • Service records for transit-authority audits
  • Card-reader and payment-module logs
  • Annual CE check
  • Integrated reporting via Aurionpro software
